Different pump heads can be used with the SCHMIDT + HAENSCH Vari peristaltic pump, resulting in flexibility in your day-to-day usage and enabling multiple tubing sizes. Depending on the tubing material in use, this pump type can be used for various chemicals, corrosive and aggressive, as well as sterile solutions.
The user-friendly membrane keyboard enables the user to regulate the flow speed (RPM) using the switch arrays.
Furthermore the user can activate a “quick flow mode” by pressing the special button on the membrane keyboard.
Via external adapters for other signals, steering the pump externally is also possible. Additionally, a foot switch can be attached to the pump to enable the pumping function as long as the foot switch is activated.
ID-N° 17643
ID-N° 17645 Chemical resistant hoses
You are currently viewing a placeholder content from YouTube. To access the actual content, click the button below. Please note that doing so will share data with third-party providers.
More Information| Specifications | |
| Speed: | 0.1 to 100 rpm, reversible |
| Speed precision: | 0.1 rpm |
| Speed control: | Membrane keypad and rotary encoded switch |
| Display: | 128 x 64 graphic LCD displays flow rate and speed (rpm) |
| Communication interface: | RS485 |
| Power supply: | 220 Vac ± 10%, 50/ 60 Hz, 110 Vac± 10%, 50/ 60 Hz |
| Power consumption: | < 50 W |
| Operating condition: | 0 to 40 °C |
| Relative humidity: | < 80% |
| Dimensions (L x W x H in mm): | 202 x 160 x 239 |
| Drive weight (without Pump Head): | 5.34 kg |
| IP code: | IP 31 |
